Customized dongfeng duolika 4*2 LHD Euro 6 diesel 6cbm asphalt tanker truck for sale, HOT SALE! Dongfeng 5tons bitumen spreading vehicle
The truck model of dongfeng 4*2 LHD 6cbm asphalt spreading tanker truck is CLW5120GLQD6 and the truck model is EQ1125SJ8CDC; 3800mm wheelbase, 6 speed gearbox, 245/70R19.5/7.50R16 tires, D30TCIF1 yunnei 170hp diesel engine/ YCY30165-60 yuchai 165hp diesel engine/ CY4SK361 chaochai 170hp diesel engine, Euro Ⅵ emission standard, air conditioner, etc.
The devices of intelligent type dongfeng brand 4cbm 3tons asphalt distributing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB680 (high viscosity asphalt pump, 680L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve, radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L;
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 34 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-3L/㎡;
7, asphalt distributing width: 4.5m, 39 sets spraying nozzles for 6m spreading width is selective (8000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of dongfeng 6cbm 5tons Euro 6 diesel asphalt tanker truck as below.
| Main technical parameters of dongfeng 6cbm asphalt spreading vehicle for sale |
| Product name |
CLW5120GLQD6 dongfeng 6cbm asphalt spreading tanker vehicle for sale |
| Total mass(Kg) |
11995 |
Tanker volume (m3) |
6 |
| Rated mass(Kg) |
5460 |
Overall dimension(L*W*H)(mm) |
7380 |
| Curb mass(Kg) |
6340 |
Driver cab seated person |
3 |
| Approach/departure angle(°) |
21/17 |
Front/rear suspension(mm) |
1130/2450 |
| Axle no. |
2 |
wheelbase(mm) |
3800 |
| Axle load(Kg) |
4350/7645 |
Max speed(Km/h) |
103 |
| Chassis main technical parameters |
| Truck chassis model |
EQ1125SJ8CDC |
manufacturer |
Dongfeng company |
| Approach/departure ang;e(°) |
21/14 |
Tire specification |
245/70R19.5,7.50R16 |
| Steel spring |
8/10+7,12/12+9 |
Front tread(mm) |
1745 |
| Fuel type |
Diesel |
Rear tread(mm) |
1630 |
| Emission standard |
Euro Ⅵ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
|
D30TCIF1
CY4SK361
YCY30165-60
|
Yunnei power
Chaochai
Yuchai
|
2977
3856
2970
|
125
125
121
|
