SINO TRUK HOWO 6*4 LHD 371hp 16cbm diesel asphalt tanker truck for sale, customized HOWO 14tons bitumen spreading tanker vehicle for sale
Customized SINO TRUK HOWO 6*4 LHD 16CBM asphalt spreading truck adopts SINO TRUK HOWO HW76 luxurious one row and a half driver cab, HW19710 10 speed gearbox, HW70 PTO, ST16 16T rear axle, 12.00R20 rail tires, ZF8198 steering wheel,etc.
The details of standard type 16cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: manual Proportional valve; the model of hydraulic motor for asphalt pump: 05-130-BD31; hydraulic pump model: CBQ550-L
3, control way: controlled the control box at the rear working platform, 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil.
5, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
6, spreading amount: 0.25-3.5L/㎡;
7, gasoline generator unit: 6KW
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
If you're interested in our SINO TRUK HOWO 6*4 LHD 336hp diesel 16cbm asphalt spreading truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of SINO TRUK HOWO 6*4 LHD 336hp diesel asphalt spreading tanker truck is as below.
| Main technical parameters |
| Product name |
CLW5250GLQZ asphalt tanker truck for sale |
| Total mass(Kg) |
25000 |
Tanker volume(m3) |
16 |
| Rated mass(Kg) |
9000 |
Overall dimension(L*W*H)(mm) |
10100×2500×3563,3420 |
| Curb mass(Kg) |
15870 |
Driver cab seated person |
×× |
| Approach/departure angle(°) |
16/10 |
Front/rear tread(mm) |
1500/2650,1500/2625 |
| Axle nos. |
3 |
wheelbase(mm) |
4600+1350,4575+1400 |
| Axle load(Kg) |
7000/18000(tri axles) |
Max speed(Km/h) |
90 |
| Truck chassis main parameters |
| Truck chassis modle |
ZZ1257 |
Manufacturer |
SINO TRUK HOWO COMPANY |
| Approach/departure angle(°) |
16/18 |
Tire specification |
295/80R22.5*10+1 |
| Steel spring |
10/12, |
Front tread(mm) |
2022 |
| Fuel type |
Diesel |
Rear tread(mm) |
1830/1830 |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
|
WD615.47
WD615.69
|
Sino truk
Sino truk
|
9726
9726
|
273
247
|
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Our asphalt distributor dopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.
Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
Advantages of chengli sensor emulsified asphalt distributor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1.The temperature rising speed is 5% faster than the trucks manufacture by other factory.
2.With conducting oil system, asphalt both in the tank and in the nozzle are all hot, easy to spray, no remained.
3.High quality metal hose, won't broken, long service life.
4.The distribution width can be adjusted according to your demand from 4.5m to 6m.
5.Start quickly, though the truck stop, still can distribute
