The asphalt sprinkling truck a kind of special purpose tank vehicle equipped with thermal container/tank, asphalt pump, heater and sprinkling system, used for sprinkling asphalt. Or we can also called a kind of pavement construction machinery for sprinkling liquid asphalt such as hot asphalt, emulsified asphalt, residual-oil ,etc. The asphalt sprinkling truck is widely used for some pavement constructions, such as highway, city street, airport road, port road, reservoir, etc. Some bigger volume asphalt sprinkling truck is also can be used for transporting asphalt, mainly for some construction and maintenance works such as Surface treatment of asphalt penetration method, In-situ mixing of permeable clay mixture with asphalt stabilized soil, etc.
Adventure of CLW brand asphalt spray truck as below.
1 Main parts such as Hydraulic pump ,asphalt pump etc all adopted European famous brand
2 Asphalt pump adopted thermal conductive oil insulation ,conservation of energy
3 Easy to control
4 It is widely use for transportation and distribution of hot asphalt,modified asphalt
5 Two ways of cleaning asphalt pump and pipeline :diesel cleaning and high pressure air cleaning , it makes spraying nozzles and pipeline clean all the time.
Dongfeng D9 10cbm bitumen distributing tanker truck, adopts dongfeng D9 one row and a half luxurious driver cab, 4500mm wheelbase, ISD180-43 Cummins 180hp Euro Ⅳ diesel engine, 9,00R20 rail tires, 4.5t front axle/10t rear axle, 8 speed manual gearbox, etc.
Performance parameter of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
- Truck model: CLW5180GLQ4
- Total mass: 18000kg
- Curb mass: 9180kg
- Overall dimension(L*W*H):8160×2500×3060mm
- Spreading width: 4500mm
- Distance between nozzles: 125mm
- Asphalt spreading amount: 0.2～3.5L/m2
- Working speed:1.5--20km/h
- Heating way: Italian imported burner heating G20(200,000 Kilocalorie/hour)
- Spreading medium: emulsified asphalt, hot asphalt, SBS BS modified pitch, modified emulsified asphalt
- Spreading inaccuracy:±2%
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of Dongfeng D9 180hp Euro 4 diesel 10cbm 8tons asphalt spreading tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
- main parts of asphalt tanker truck as below:
| Item |
Name |
Model, specs |
Affiliation System |
Remark |
| 1 |
Truck chassis |
EQ1185 |
Chassis |
250mm boom, power steering and air cut baking, etc. |
| 2 |
Engine |
ISD180- ISD180-43 |
| 3 |
Gearbox |
8 speed gearbox, manual |
| 4 |
Tires specification |
10.00R20 |
| 5 |
Front/rear axle |
Front axle: 4.5T；rear axle:10T, |
| 5 |
Asphalt tanker volume |
10cbm |
Tanker |
High quality carbon steel |
| 6 |
Thickness of insulating layer |
50mm thickness |
Rock wool insulation |
| 7 |
Covered with stainless steel |
1mm thickness |
1mm stainless steel plate |
| 8 |
PTO |
Specialized for spreading vehicle |
Source of work motivation |
|
| 9 |
Hydraulic pump |
CBQ550-L |
Hydraulic system |
Tianjin |
| 9 |
Proportional Valve |
EFRD-G03-160-5-31 |
Northman |
| 10 |
SOLENOID Directional Valve |
SWH-G03-D24-20 |
Northman |
| 11 |
overflow valve |
MT-02 |
Northman |
| 12 |
radiator |
AH1012T |
GUANGZHHOU Hercules |
| 11 |
Motor for hydraulic pump |
05-110BD40 |
Tianjin/ningbo |
| 12 |
Asphalt pump |
QGB950 |
Asphalt spreading system |
shanggui, 950L/min |
| 13 |
Nozzles nos. |
36sets |
Control mode:1 controls 1 |
| 14 |
Handlance |
5m length hose+1.5m length manual nozzle |
边角位置补洒 |
| 15 |
Burner |
G20(200,000万kilocalorie/hour) |
Heating system |
Italy Riello |
| 16 |
Heat conducting oil pump |
RY32-32-160 |
Hebei |
| 17 |
Heat conducting oil pump motor |
380V-2.2KW-2 grade |
Anhui liu’an |
| 18 |
Control system mode |
Driver Cab touch-screen computer control +rear working platform control(reserve) |
Controlling system |
The control system adopts USA cylindro controller.,faster and smoother operation, low failure rate |
| 19 |
Velocity sensor |
Ni5-G12 |
GERMAN TURCK |
| 20 |
Temperature controller |
Pt100 |
SHANGHAI XINGHUI |
| 21 |
Generator |
LT10000EN3-4 |
Power system |
Lutian 6kw gasoline generator unit |
