This dongfeng brand TIANJIN 4*2 LHD 8tons flatbed wrecker towing truck adopts dongfeng TIANJIN 4*2 LHD one row and a half luxurious driver cab, 5000mm wheelbase, Fastgear 8 speed manual gearbox, B6.2NS6B210 Cummins 210hp Euro 6 diesel engine, air cut brake, 10.00R20 rail tires, 4.5tons front axle/9tons rear axle, original air conditioner, 280L steel oil tanker, etc.
The length of the flatbed for the dongfeng 153 wrecker tow truck is 7200mm; while the width of the flatbed is 2550mm,
The standard devices of dongfeng tianjin 4*2 LHD 8tons road wrecker tow truck as below
1, 6 tons loading capacity for the upper part/flatbed
2, 6T hydraulic winch and 45m length wire rope
3, 5tons loading capacity of rear towing arm(choose to install)
4, auxiliary wheels*2 sets
5, bilateral linkage control valve
6, fully hydraulic flipping plates
7, caller with alarm light
8, 6* special binding belts
Flatbed tow truck consists of the chassis, hoisting equipment,truck tow hook, tow truck winch, tow truck wheel lift, hydraulic system, electric control system, truck body and the tool boxes.
The rollback tow truck can hoist, lift, draw and be with other special functions, mainly used in highway, garage and city road obstacle cleaning.
As a china tow truck manufacturers , our rescue vehicle can meet all your demand. Right hand rollback tow truck, left hand drive rollback tow truck, 4x2 wreckers, 6x4 wreckers, 8x4 tow wrecker trucks,etc. In wrecker types, we produce plat form tow truck, under lift wrecker truck, rotator tow truck, full landing rollback tow truck, double flatbed wrecker truck, etc.
the technical advantages of CLW Brand wrecker towing truck as below.
1. small angle of flatbed to ground, easy for broken car to be on it.
2. Thick good quality checker plate platform, long service time, skid-proof
3. Adpot Italy imported special balance valve.
4. Operate on both sides of the truck and remote is available.
More pictures of dongfeng tianjin 8tons flatbed wrecker truck is as below.
If you're interested in our wrecker towing truck, please send email to truck0011@163.com or talk to Anita by WHatsapp: 0086 1332989995.
Website: www.trucksinchina.com
main technical parameters of dongfeng tianjin 8T flatbed wrecker towing truck is as below.
| Overall parameters |
Product name |
Dongfeng Tinajin 8tons flatbed wrecker tow truck for sale |
| Manufacturer |
Chengli Special Automobile Co., Ltd. |
| Total mass(kgs) |
18000 |
| Curb mass(kgs) |
10420 |
| Overall dimension (L*W*H)(mm) |
9650×2550×2830 |
| Chassis parameters |
Driver cab |
dongfeng 4*2 LHD single row driver cab with 3 seats |
| Approach/departure angle(°) |
17/13 |
| Front/rear suspension(mm) |
1400/3400 |
| Axles nos. |
2 |
| Wheelbase(mm) |
5000 |
| Axle load(kgs) |
6500/11500 |
| Max speed(km/h) |
89 |
| Tire specification |
10.00R20*6+1 |
| Steel spring |
8/9+6 |
| Front/rear tread(mm) |
1980/1860 |
| Engine model |
B6.2NS6B210 |
| Fuel type |
Diesel |
| Emission standard |
Euro Ⅲ |
| Gearbox |
Fastgear 8 speed gearbox, manual |
|
Upper part parameters
|
Flatbed dimension(L*W)(mm) |
7200*2550 |
| Hydraulic winch loading capacity |
8tons |
| Operation way |
Bilateral linkage operation |
| Rear towing arm |
8tons loading capacity of the rear towing arm |
| Loading capacity of the flatbed plate |
8tons |
| Wire rope |
45m length wire rope |
| Special binding belts |
6 sets |
| Caller with alarm light(yellow color) |
Yes |
| fixation forks |
2 sets |
| |
Supporting forks seat |
1 set |
| |
fixation forks |
2 sets |
