The tow truck is also called road tow truck, road wrecker, wrecker tow truck, wrecker, towing truck, breakdown truck, wrecker truck, recovery truck, road rescue vehicle, etc.
Our flatbed tow truck consists of the chassis, hoisting equipment,truck tow hook, tow truck winch,tow truck wheel lift, hydraulic system, electric control system, truck body and the tool boxes.
The rollback tow truck can hoist, lift, draw and be with other special functions, mainly used in highway, garage and city road obstacle cleaning.
As a china tow truck manufacturers , our rescue vehicle can meet all your demand. Right hand rollback tow truck, left hand drive rollback tow truck, 4x2 wreckers, 6x4 wreckers, 8x4 tow wrecker trucks,etc. In wrecker types, we produce plat form tow truck, under lift wrecker truck, rotator tow truck, full landing rollback tow truck, double flatbed wrecker truck, etc.
the technical advantages of CLW Brand wrecker towing truck as below.
1. small angle of flatbed to ground, easy for broken car to be on it.
2. Thick good quality checker plate platform, long service time, skid-proof
3. Adpot Italy imported special balance valve.
4. Operate on both sides of the truck and remote is available.
Customized dongfeng brand 4*2 LHD 4T flatbed wrecker towing truck adopts dongfeng duolika 4*2 LHD 2050mm single row driver cab, 3800mm wheelbase, CY4102BZQ 120hp diesel engine, 5 speed gearbox, air cut braking, 7.50R16 rail tires, power steering+ wheel steering, etc.
The loading capacity of the flatbed type wrecker tow truck is 4tons, and the length of the flatbed is 5.6m; the width of the flatbed is 2.3m; while the length of the tail plate is 1m, which can be designed and manufactured as hydraulic folded flipping plate. So the length of the flatbed of dongfeng duolika wrecker tow truck is 6.6m (5.6m+1m),
The standard devices of dongfeng duolika 4*2 LHD road wrecker tow truck as below
1, 3 tons loading capacity for the upper part/flatbed
2, 4T hydraulic winch and 20m length wire rope
3, Retractable Rear Lift Arm (choose to install)
4, auxiliary wheels*1
5, bilateral linkage control valve
6, fully hydraulic flipping plates
7, yellow color alarm light
8, 4* special binding belts
If you're interested in our wrecker towing truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of dongfeng 4tons wrecker towing truck is as below.
HOT SALE!DONGFENG DUOLIKA 4T-5T wrecker towing truck for sale
Main technical parameters of dongfeng 4tons wrecker towing truck is as below.
| Overall parameters |
Product name |
dongfeng 4 wrecker tow truck for sale (CLW5070TQZP3) |
| Manufacturer |
Chengli Special Automobile Co., Ltd. |
| Product model |
CLW5070TQZP3 |
| Total mass(kgs) |
7490 |
| Curb mass(kgs) |
5495 |
| Overall dimension (L*W*H)(mm) |
7420×2300×2540 |
| Chassis parameters |
Driver cab |
dongfeng 4*2 LHD single row driver cab with 3 seats |
| Approach/departure angle(°) |
20/10 |
| Front/rear suspension(mm) |
1180/2440 |
| Axles nos. |
2 |
| Wheelbase(mm) |
3800 |
| Axle load(kgs) |
3150/4340 |
| Max speed(km/h) |
90 |
| Tire specification |
7.00R16 8PR*6 |
| Steel spring |
11/9+7,8/10+7 |
| Front/rear tread(mm) |
1835/1640 |
| Engine model |
Yuchai 120hp |
| Fuel type |
Diesel |
| Emission standard |
Euro Ⅲ |
| Gearbox |
5 speed gearbox, manual |
|
Upper part parameters
|
Flatbed dimension(L*W)(mm) |
5600*2300 |
| Rear hydraulic flapping plate Length (mm) |
1000 (it is selective) |
| Total flatbed length (mm) |
5600+1000 |
| Hydraulic winch |
4tons |
| Operation way |
Bilateral linkage operation |
| Rear towing arm |
2.5tons loading capacity fo the rear towing arm |
| Loading capacity of the flatbed |
4tons |
| Wire rope |
20m length |
| Auxiliary wheels |
1 sets |
| Special binding belts |
4 sets |
| Yellow color alarm light |
Yes |
